Current Rated: 60A Direct Input
Nullam bulit-in
Nam PROMUTUUS / Postpaid Billing System
Ratum Voltage: 230V
WiFi Communication libitum
RS485 Communication
+86-18702106858 / +86-21-69156352
ADL200-NK est energia multifunctionis metri electrici variis systematibus electricis destinata. Aestimationem monetae 60A directae initus et intentionis aestimatae 230V, aptam ad normas residentiales et commerciales applicationes faciens.
Hoc metrum sustinet et systemata exosculatio promulgationem et postmissam, flexibilitatem in solutione optionum offerens. Optiones Communicationis includunt RS485 et WiFi ad libitum, ut integrationem inconsutilem in moderno craticula dolor ac industria systemata administrandi efficiant.
Eius consilium compactum et functionalities provectae electionem idealem faciunt ad industriam efficientis vigilantiam et procurationem.
| Technical Parameter | ADL200-NK | ||
| Measu rement | Voltage | Relatio voltage | 220V |
| Consummatio | <10VA(singula phase) | ||
| Impedimentum | >2M Ω | ||
| Sagaciter | ±0.2% | ||
| Input Current | 10(60) A | ||
| Current | Consummatio | <4VA (canalis singularis currentis aestimavit) | |
| Sagaciter | ±0.2% | ||
| Potentia activa, potentia reactiva, potestas apparentis, error | |||
| Potestas | |||
| Frequency | 45 ～ 65Hz . Error ± 0.2% | ||
| Meteri ng | Electric Energy | active electrica industria genus I " | |
| Reactivum electrica industria genus II " | |||
| Horologium accurate | ≤0.5s/d | ||
| Digital signum | Potestas pulse output | I potentia activa optocoupler output | |
| Pulsus | Pulsus Width | 80±20ms | |
| Pulsus constant | 1600imp/kWh | ||
| Comm unicati on | Interface and communicationis protocol | RS485 Interface . Modbus RTU communicationis | |
| Communication oratio range | Modbus RTU:1~ 247 | ||
| Baud rate | 1200bps~19200bps | ||
| Enviro nment s | Opus temperatus | -25 ℃ ~ 55 ℃ | |
| Repono Temperature | -40 ℃ ~ 70 ℃ | ||
| Relativum humiditas | ≤95℅ (Nulla condensatio) | ||
| altitudo | <2000m | ||
